    8 Meter Self Propelled Scissor Working Platform With 800mm Extension Platform

    Ask Lasest Price
    Brand Name : SIVGE
    Model Number : GTWZ8-4008
    Certification : CE / SGS / ISO9001
    Price : negotiation
    Payment Terms : T/T, L/C, D/P, D/A
    Supply Ability : 30 units per month
    Delivery Time : 7-50 work days
    • Product Details
    • Company Profile

    8 Meter Self Propelled Scissor Working Platform With 800mm Extension Platform

    8m self propelled scissor working platform / scissor lift with 800mm extension platform

    Occasions suitable to use this machine:


    Places may in need of this kind of machine:

    Office buildings, warehouses, factories, business/convention center, airports, auto stations and highway toll station etc.


    Product Description

    Using purpose:

    Business decoration, ceiling/fixture works, industrial facilities maintenance, lamps and lanterns replacement in halls, maintenance of street lamp, aerial photographs and wall cleaning etc.


    Product standard features

    • Drivable at full height

    • One hand proportional joystick

    • AC inverter motor drive

    • Drive speed interlock

    • Tilt level sensor with audible alarm

    • Overload limit

    • Emergency stop buttons at both controls

    • Emergency lowering device in case of power supply failure

    • Battery charger indictor

    • Forklift pocket

    • Compact size with easy quick guardrail assemblage system

    • Low maintenance requirements will save you time and money.

    Specification

    8m self propelled scissor working platform / scissor lift with 800mm extension platform


    BrandSIVGE
    Model-CodeGTWZ8-4008
    Max. Platform Height8m
    Max. Working Height (m)10m
    Loading Capacity (kg)400
    Number Of Person Allowed2 persons
    Platform Dimension (mm)1760×860
    Horizontal Extension (mm)800 (optional)
    Rated load for extension (kg)100(optional)
    Power SupplyDC24V&DC48V
    Motor

    For Lifting (kw): 2.2 For traveling (kw): 3.0

    Traveling speed (km/h)

    Stored state: 2.5

    Lifted state: 0.8

    Min. swerve radius (m)2.5
    Stowed Dimension (mm)L×W×H: 2430×1150×1980
    Machine weight about(kg)2450
    • rated load for extenson: 100kg
    • Optional funtion: horizontal extension platform for 800mm at one side;

    If the above specification can not fulfill your working site, such as machine length, width and height, please contact us for further design service.


    Product photos


    8 Meter Self Propelled Scissor Working Platform With 800mm Extension Platform
    Packing & Shipping

    LCL: plywood case with steel pallet at bottom

    FCL: steel pallet with anti-rust covers 20GP container for 4 set

    Delivery time is usually 40 days according to order qty. and models.


    After-sale Service

    • To provide a lifetime goods services for all Sivge equipments, included equipment maintenance, spare parts supply, provide manuals and video,etc.
    • To provide remote service support by phone and network freely.
